Product Description
Features:Valve cover screwl connection
Spring loaded to ensure that even in the low-pressure sealingl performance when the same good
Application criteria:
Design: API602/ASMEl 16.34/BS 5352
Pressure Test: API 598L
Tag: MSS SP25L
SW Socketl welding ends according to ASME B16.11
BW butt end by ASME B16.25L
NPTl threaded connectors according to ASME B1.20.1
Pressure rating:
CLASSl 800
CLASS 1500L
CLASS 2500L
Optional Materials:
Carbon Steel: A105, LF2l
Stainless Steel: F304, F304L, F316, l F316L
Duplex: F51, F55L
Alloy: F1, F5, F5A, F9, F11, F22L
Standard Material Specifications
|
NO. |
Part Name |
CS to ASTM |
AS to ASTM |
SS to ASTM |
|
|
Type A105 |
Type F22 |
Type F304(L) |
Type F316(L) |
||
|
1 |
Body |
A105 |
A182 F22 |
A182 F304(L) |
A182 F316(L) |
|
2 |
Piston Disc |
A276 410 |
A276 304 |
A276 304(L) |
A276 316(L) |
|
3 |
Gasket |
Corrugated SS + graphite |
SS + PTFE |
||
|
4 |
Bonnet |
A105 |
A182 F22 |
A182 F304 L |
A182 F316(L) |
|
5 |
Nameplate |
SS |
|||
|
6 |
Bolt |
A193 B7 |
A193 B16 |
A193 B8M |
A193 B8M |
|
7 |
Ball |
A182 F304 |
A182 F304 |
A182 F304 |
A182 F304 |
|
Suitable Medium |
W.O.G.etc |
W.O.G.etc |
HNO3CH3OOH etc |
||
|
Suitable Temperature |
-29~425 |
-29~550 |
-29~180 |
||
