Products details:

Product name：API/DIN carbon steel Electric flange knife gate valve

Product Catalog：knife gate valve

OnLine Service:

Print this Page

Bookmark this

Skype Online

E-mail Us

PDF Download

【Prev Products】

【Next Products】

Product Details	Online Inquiry

Electric knife gate valve


PN MPA	DN	L	D	D1	Coupled protruding part diameter	H	N-M	PN MPA	DN	L	D	Centround diameter	H	N-M
0.6	50	48	140	110	90	680	4-M12	1.0	350	90	500	460	1550	16-M20
	65	48	160	130	110	710	4-M12		400	100	565	515	1570	16-M22
	80	50	185	150	125	730	4-M16		450	120	615	565	1660	20-M22
	100	50	205	170	145	770	4-M16		500	130	670	620	1800	20-M22
	125	50	235	200	175	820	8-M16		600	130	780	725	2010	20-M27
	150	70	260	225	200	890	8-M16		700	160	895	840	2300	24-M27
	200	70	315	280	255	980	8-M16		800	160	1010	950	2600	24-M30
	250	70	370	335	310	1100	12-M16		900	160	1110	1050	3000	28-M30
	300	80	435	395	362	1200	12-M20		1000	160	1220	1160	3400	28-M30
	350	90	485	445	412	1450	12-M20		1200	200	1450	1380	3700	32-M36
	400	100	535	495	462	1570	16-M20
	450	120	590	550	518	1660	16-M20	1.6	50	48	160	125	680	4-M16
	500	130	640	600	568	1800	16-M20		65	48	180	145	710	4-M16
	600	130	755	705	670	2110	20-M22		80	50	195	160	730	8-M16
	700	160	860	810	775	2300	24-M22		100	50	215	180	770	8-M16
	800	160	975	920	880	2600	24-M27		125	50	245	210	820	8-M16
	900	160	1075	1020	980	3000	24-M27		150	70	280	240	890	8-M20
	1000	160	1175	1120	1080	3400	28-M27		200	70	335	295	980	12-M20
	1200	200	1400	1340	1295	3700	32-M30		250	70	405	355	1100	12-M22
1.0	50	48	160	125	100	680	4-M16		300	80	460	410	1200	12-M22
	65	48	180	145	120	710	4-M16		350	90	520	470	1450	16-M27
	80	50	195	160	135	730	4-M16		400	100	580	525	1570	20-M27
	100	50	215	180	155	770	8-M16		450	120	640	585	1660	20-M30
	125	50	245	210	185	820	8-M16		500	130	705	650	1800	20-M36
	150	70	280	240	210	890	8-M20		600	130	840	770	2010	24-M36
	200	70	335	295	265	980	8-M20		700	160	910	840	2300	24-M36
	250	70	390	350	320	1100	12-M20		800	160	1020	950	2600	28-M36
	300	80	440	400	368	1200	12-M20		900	160	1120	1050	3000	28-M42
									1000	160	1255	1170	3400	28-M42
									1200	200	1485	1390	3700	32-M48
