Product name：API/DIN electric wcb ceramic flange ball valve

Product Catalog：ceramic valve

OnLine Service:

Print this Page

Bookmark this

Skype Online

E-mail Us

PDF Download

【Prev Products】

【Next Products】

Product Details	Online Inquiry

Application Specification
1. Design and Manufacture: GB/T 12224
2. Face to Face Dimension: Manufacturer's Standard
3. Flange Dimension: JB/T 79.1, ANSI B16.5 DIN 2543, JIS B2020
4. Inspection and Test: GB/T 9092
5. Material Standard: GB/T 12229 for Carbon Steel, GB/T 12230 for Stainless Steel

Materials for Main Parts

Sr.No.	Part	Material	Sr.No.	Part	Material
1	Valve Cover	WCB	12	Hex Nut	Grade 8
2	Middle Body	WCB	13	Stud	B7
3	Middle Body Sleeve	Ceramic	14	Packing Gland	WCB
4	O-Ring	Viton	15	Spacer	Q235
5	Flange Sleeve	Ceramic	16	Circlip for Shaft	65Mn
6	Ball	Ceramic	17	Handle	CS
7	O-Ring	Viton	18	Gasket	Q235
8	Dish Spring	50CrVA	19	Screw	35#
9	Washer	304	20	Hex Bolts	B7
10	Stem	2Cr13	21	Big Washer	PTFE
11	Packing	PTFE	22	Seat	Ceramic
