DIN/API three way ball valve

Three Way Ball Valve

Standards compliance

Design and Manufacture: API 608,API 6D,BS5351

Face to face(end to end): ANSI B16.10,API 6D

Flanged connection:2"~24" to ANSI B16.5

Fire-safe: API 607,API 6FA

Butt welded end: ANSI B16.25

Test and inspection: API 598,API 6D



Usage
Way ball valve with T-shaped and L-shaped. T-shaped pipe to make three orthogonal interconnected and cut off the third channel, divert traffic, merging effect. L-shaped connecting only two orthogonal channels, can not maintain a third pipe connected with each other only as a distribution function.

Features
1, three-valve integrated in the structure of a structure, 4 seat sealing surface type, flange connection, high reliability, design and implementation of the lightweight.
2, three core sub-T-ball and L-shaped, long life, flow capacity, small resistance.

3, valve-action points by single and double acting two types, single-action feature is that once the power source fails, the ball will be in the state of the control system requirements.

Specifications

Material	WCB			CF8
Pressure(Mpa)	1.6	2.5	4.0	1.6	2.5	4.0
Temperature(oC)	<150
Medium	Water, steam, oil, etc.			Weak corrosive media
Body	Carbon steel castings			Chrome-nickel-titanium steel casting
Ball, Stem	2Cr13			Chrome-nickel stainless steel titanium
Seat	RPTFE
Packing	PTFE
