API gear operation welded forged steel ball valve

Full forged ball valve dimension:(mm)


DN	PN			PN			PN			PN
	1.6MPA			2.5MPA			4.0MPA			6.4MPA
	L	D	H	L	D	H	L	D	H	L	D	H
50	216	65	190	216	65	190	216	65	190	292	75	210
65	241	80	200	241	80	200	241	80	200	330	90	220
80	283	95	210	283	95	210	283	95	210	356	105	240
100	305	115	220	305	115	220	305	115	220	400	125	260
125	381	140	260	381	140	260	381	140	260	406	150	280
150	457	165	290	457	165	290	457	165	290	495	175	320
200	521	225	325	521	225	325	521	225	325	597	235	360
250	559	280	410	559	280	410	559	280	410	673	295	440
300	635	330	435	635	330	435	635	330	435	762	348	480
350	762	385	480	762	385	480	762	385	480	826	405	505
400	838	440	505	838	440	505	838	440	505	902	455	555
450	914	490	605	914	490	605	914	490	605	978	520	670
500	9910	550	625	9910	550	625	9910	550	625	1054	570	720
600	1143	660	660	1143	660	660	1143	660	660	1232	680	760
700	1346	765	740	1346	765	740	1346	765	740	1397	800	840
800	1524	870	850	1524	870	850	1524	870	850	1651	910	960
900	1727	970	1020	1727	970	1020	1727	970	1020	1880	1020	1150
1000	1780	1080	1170	1780	1080	1170	1780	1080	1170	1990	1140	1350
