Cast Floating Ball Valve

DIN/ANSI forged A105 floating flange ball valve

Bolted bonnet,Two-piece Body,Floating Ball

Full or Reduced bore,Blowout Proof Stem

Fire safe and Anti static

Stainless steel ball

ASTM A216 WCB,A351 CF8,A351 CF8M,

A351 CF3,A351 CF3M,A351 CN7M

Standards compliance

Design and Manufacture: API 608,API 6D,BS5351

Face to face(end to end): ANSI B16.10,API 6D

Flanged connection:2"~24" to ANSI B16.5

Fire-safe: API 607,API 6FA

Butt welded end: ANSI B16.25

Test and inspection: API 598,API 6D

Major parts materials

NO	Part name	Material	NO	Part name	Material
1	Bonnet	A216-WCB	9	Gasket	PTFE
2	Nut	A194-2H	10	Packing	Graphite
3	Gasket	Graphite	11	Gland	A216-WCB
4	Bolt	A193-B7	12	Screw nail	A194-2H
5	Body	A216-WCB	13	Locating piece	Carban steel
6	Seat	PTFE	14	Ring	AISI 1566
7	Ball	A105	15	Wrench	A47-667
8	Stem	A276-410
