Products details:

Product name：stainless steel male thread hydraulic fitting

Product Catalog：flange -fitting-Parts and other valve

OnLine Service:

Print this Page

Bookmark this

Skype Online

E-mail Us

PDF Download

【Prev Products】

【Next Products】

Product Details	Online Inquiry

Product Description

	E	HOSE BORE		DIMENSIONS
PART NO.	THREAD E	DN	DASH	A	C	S1
15611-02-03	Z1/8"X27	5	3	22.5	10.5	12
15611-02-04	Z1/8"X27	6	4	22.5	10.5	12
15611-04-03	Z1/4"X18	5	3	27.5	15	17
15611-04-04	Z1/4"X18	6	4	28	15	17
15611-04-05	Z1/4"X18	8	5	28	15	17
15611-04-06	Z1/4"X18	10	6	27	15	17
15611-06-04	Z3/8"X18	6	4	28	16	19
15611-06-05	Z3/8"X18	8	5	28	16	19
15611-06-06	Z3/8"X18	10	6	30	16	19
15611-06-08	Z3/8"X18	12	8	30.5	16	19
15611-08-06	Z1/2"X14	10	6	34.5	19.5	22
15611-08-08	Z1/2"X14	12	8	34.5	19.5	22
15611-08-10	Z1/2"X14	16	10	36	19.5	22
15611-12-08	Z3/4"X14	12	8	37.5	19.5	27
15611-12-10	Z3/4"X14	16	10	38	19.5	27
15611-12-12	Z3/4"X14	20	12	38.5	19.5	27
15611-12-16	Z3/4"X14	25	16	39.5	19.5	32
15611-16-10	Z1"X11.5	16	10	45	25.5	36
15611-16-12	Z1"X11.5	20	12	45	25.5	36
15611-16-16	Z1"X11.5	25	16	44.5	25.5	36
Note:1.For use with braide hoses.2.if use with spiral hoses,hose fitting series number is 15612-xx-xx
