Design Standard

API 594, API 6D, JB/T8937

Face to Face

API 594, API 6D, JB/T8937, DIN3202

Flange Ends

ANSI B16.5, DIN2543~48, JB/T9112~24

Test & Inspection

API598, DIN3230, JB/T9092

NO.

Part Name

WCB(A105)

CF8(304)

CF3(304L)

CF8M(316)

CF3M(316L)

1

Body

WCB(A105)

CF8(304)

CF3(304L)

CF8M(316)

CF3M(316L)

2

Disc

WCB/CF8

CF8

CF3

CF8M

CF3M

3

Stem

2Cr13

304

304L

316

316L

4

Spring

0Cr18Ni9

0Cr18Ni9

00Cr19Ni10

0Cr17Ni12Mo2

0Cr17Ni14Mo2

Suitable Medium

W.O.G.etc

HNO3,CH2OOH etc

Suitable Temperature

-29~425 oC

-196~540 oC

Class

SIZE

2"

21/2"

3"

4"

5"

6"

8"

10"

12"

14"

16"

18"

20"

24"

150

D

105

124

137

175

197

222

279

340

410

451

515

550

607

718

L

60

67

73

73

86

98

127

146

181

185

191

203

219

223

d

60

73

89

114

141

168

219

273

324

360

412

440

484

572

Weight

2.5

3.5

4.4

6.5

10

12

25

43

58

80

118

210

240

410

300

D

112

130

149

181

216

251

309

361

422

484

540

L

60

67

73

73

86

98

127

146

181

223

232

d

64

77

94

120

146

175

226

280

332

368

420

Weight

3

4.2

5.3

7.8

12

13.2

30

51

88

128

169

600

D

110

129

148

192

265

319

399

456

L

61

67

73

80

137

165

213

229

d

64

77

94

120

146

175

226

280

Weight

3.5

5

7

12

35

45

77

110

900

D

142

164

167

205

289

359

L

70

83

95

102

159

207

d

64

77

94

120

146

175

Weight

6.5

9

14

24

43

56
