Static sound type Check Valves

1、 Product characteristic and use

Static sound type Check Valves Mainly by the valve chest, the valve seat, the conduction current body, the valve petal, the bearing and the spring and so on the major parts is composed, the internal flow channel uses the streamline form design, the pressure loss is minimum. The valve petal opens shuts the traveling schedule to be very short, stops when the pump may close fast, prevented the giant impingement sound, has the static sound closure characteristic.
This valve mainly uses in giving draining water, the fire prevention, passing the system warmly, may install in the water pump exit, prevented flows backwards and the impingement to harm。

2、Main technical parameter

type		DRVZ-10	DRVZ-16	DRVZ-25Q
Nominal pressure		PN1.0MPa	PN1.6MPa	PN2.5MPa
Nominal diameter		DN50~250mm
Maximum operating pressure		PN1.0MPa	PN1.6MPa	PN2.5MPa
Seal test pressure		PN1.0MPa	PN1.6MPa	PN2.5MPa
Shell test pressure		PN1.5MPa	PN2.4MPa	PN3.75MPa
Main parts materials	Body 、 diffuser insert	gray cast iron		Ductile Cast Iron
	seat 、 Bearing 、 Disc Disc 、 Axial	albronze or Chromium Stainless Steel
	Spring		Stainless Steel

3、Main external dimensions (flange size PN1.0Mpa according to GB4216.4-84 standard, PN1.6MPa according to GB4216.5-84 standard, PN2.5Mpa according to GB9113.4-88 standard,)

DN（mm）	L
50	120
65	150
80	180
100	240
125	300
150	350
200	450
250	500
